| NUMBER OF BOOMS | 4 SECTIONS |
| FOLDING TYPE | Z TYPE |
| VERTICAL HEIGHT | 37.1m (121'9) |
| HORIZONTAL REACH | 33.1m (108'7) |
| PIPE SIZE (ID) | 125 mm (5") |
| BOOM CONTROL VALVE | Proportional (by HAWE) |
| RADIO REMOTE | Dual Wireless Transmitter System |
| VIBRATOR | Standard |
| WATER PUMP | Hydraulic Power 20 bar (290 psi) |
| WATER TANK | 800 L (211 G) |
| WEAR PARTS | Carbide |
| POPULAR UPGRADES |
• LED Boom Light Kit • LED Outrigger Lights • Heated Water Tank • Heated Hydraulic Tank • Air-Cuff • Twin Wall Pipe • 20 Cell Pump Kit • 18 Cell Pump Kit |
| NUMBER OF BOOMS | 4 Sections |
| FOLDING TYPE | Z Fold |
| VERTICAL HEIGHT | 37.1m (121'9") |
| HORIZONTAL REACH | 33.1m (108'7") |
| UNFOLDING HEIGHT | 8.9m (29'2") |
| 1ST SECTION | 7.85m (25'9") |
| 2ND SECTION | 7.94m (26'1") |
| 3RD SECTION | 8.33m (27'4") |
| 4TH SECTION | 12.0m (39'4") |
| OUTRIGGER | X-Style |
| FRONT SPREAD | 6.3m (20'8") |
| REAR SPREAD | 7.0m (23') |
| OUTRIGGER MAX LOAD | 16,828 kg | 37,100 lb |
| OUTPUT: |
Rod Side: 164 m3/h (215 yd3/h) Piston Side: 102 m3/h (133 yd3/h) |
| PRESSURE: |
Rod Side: 72 Bar (1044 psi) Piston Side: 115‡ bar (1668 psi) |
| CONCRETE CYLINDER DIAMETER | 230 mm (9") |
| CONCRETE CYLINDER TYPE | Hard Chromed |
| STROKE LENGTH | 2100 mm (83") |
| S-TUBE SIZE | 9" x 7" |
| MAIN OIL PUMP |
Rexroth hydromatic A11VLO260 |
| HYDRAULIC SYSTEM PRESSURE | 350 bar (5076 psi) |
| LUBE SYSTEM (HOPPER) | Automatic |
| SWITCHING SYSTEM | Hydraulic |
| HOPPER CAPACITY | Easy Clean 600 L (158 G) |
| NUMBER OF STROKES/MIN | 31 |
| OUTPUT CONTROL RANGE | 10(13)~164m3/h (215yd3/h) |
